Decorative Chinese-style and T-type interlocking tiles for heritage, cultural-tourism and feature roofing. Injection-molded from PP (or fiberglass-reinforced PP) for a crisp, glazed-tile look at a fraction of the weight of real ceramic — for eaves, ridges, pavilions and feature façades.
This family is different from our ASA synthetic resin roof line. These are injection-molded decorative tiles — Chinese-style glazed profiles, eaves and ridge components, and T-type interlocking units — made for the look of a traditional tiled roof, most often on heritage, cultural-tourism and feature buildings.
The crisp glazed-tile silhouette of Chinese antique roofing — ridge caps, eaves drops, barrel courses — molded from PP or fiberglass-reinforced PP so it will not fade, crack or grow moss the way fired clay does, and weighs a fraction as much.
The T-type units interlock side-to-side for fast, aligned laying and a clean weather seal — well suited to decorative courtyard walls, gate houses and pavilion roofs.
Best used as a decorative roof and trim system — temple and pavilion eaves, cultural-tourism streets, restaurant and shop frontages, scenic-area feature walls. For a full load-bearing house roof we point buyers to our ASA resin or stone-coated metal lines.
Performance figures for this decorative family are model-specific. Where we do not yet hold a verified test value we mark it TBD · per factory TDS rather than publish an estimate.
Decorative components and interlocking units — mixed and matched per project.
Glazed-look barrel courses, ridge caps and eaves drops for temple, pavilion and heritage roofs.中式仿古琉璃瓦
Side-interlocking units for fast, aligned laying on decorative courtyard and gate-house roofs.T型连锁瓦
Matching ridge, hip, gable and drip components to finish a traditional roofline cleanly.勾头 / 滴水 / 脊瓦
Representative sizes from the FG-110 antique series. Full model list and matching trims quoted per project — tell us the roof style and we return the component schedule.
| Model | Material | Overall width | Effective width | Thickness | Profile height |
|---|---|---|---|---|---|
| FG-110-30 | PP | 1100 mm | 1060 mm | 3 mm | 30 mm |
| FG-110-95 | PP | 1100 mm | 1060 mm | 3 mm | 95 mm |
| FG-110-180 | PP | 1100 mm | 1060 mm | 3 mm | 180 mm |
| T-type interlock | PP / FRP | per model | per model | 3 mm | interlocking |
| Ridge / eaves trim | PP / FRP | component | — | per model | — |
Heights shown span the published FG-110 range (30–180 mm). Length, weight per piece and full model codes are confirmed on the project component schedule.
A deliberately short table: confirmed figures only. Decorative-family performance values we have not verified are marked TBD and issued from the factory datasheet per order.
| Material | Polypropylene (PP) or fiberglass-reinforced PP (FRP) |
|---|---|
| Construction | Injection-molded / single or composite layer (not ASA co-extruded) |
| Typical thickness | 3 mm |
| Overall / effective width | 1100 mm / 1060 mm (FG-110 series) |
| Profile height range | 30 – 180 mm across models |
| Primary use | Decorative / heritage roofing & trim (not primary load-bearing roof) |
| Weight per piece | TBD · per factory TDS |
| Service life | TBD · per factory TDS |
| Fire rating | TBD · per factory TDS (standard no. on report) |
| Operating temperature | TBD · per factory TDS |
| Wind / load | TBD · per factory TDS |
We would rather show an honest TBD than a guessed number. Request the datasheet pack for a specific model and we send the verified values with the quote.
Decorative and cultural projects where the roofline is part of the design.
Pavilions, gate houses and tourism-street roofs with a traditional glazed look.
Feature eaves and awnings that give a themed frontage instant character.
Decorative ridge and wall-cap courses for gardens and courtyard architecture.
Tell us the roof style and we return a matched component schedule — courses, ridges, eaves and interlock units in one palette.
Real molded sample and color reference — shipped to your door. 24-hour quote with the model datasheet on request.
