A composite roofing tile with a galvanized steel core bonded between an ASA weather cap and a PVC base. It marries the load-bearing strength of steel with the acid-, alkali- and salt-resistance of engineering resin — built for industrial and highly corrosive environments where both a bare metal sheet and a plain resin tile fall short.
PSP tile is our industrial anti-corrosion line. It is a different animal from our synthetic resin tile — it has a steel core inside, so it carries load like metal while the resin skins keep it from rusting.
A galvanized steel core gives the tile the span and load-bearing capacity of a metal roof, while the ASA and PVC layers seal the steel away from acid rain, salt air and chemical fumes that would rust a bare sheet within years.
It is specified where ordinary color-coated steel fails fast — chemical and fertilizer plants, coastal and high-salt zones, aquaculture and wet processing. The resin skin resists acids, alkalis and salts that eat through paint and zinc.
The metal core lifts fire performance to Class A (tested by China's national fixed-fire-fighting & fire-resistant components quality inspection centre) — a level plain resin tile (B1) cannot reach.
The composite build damps rain noise and drum, insulates better than bare metal, and has a low thermal-expansion coefficient so it stays dimensionally stable across hot-cold cycling. Color is held in the ASA cap, not surface paint.
Unlike our pure-resin tile, the PSP tile has a metal heart. The steel core is laminated between an ASA weather cap and a PVC base so the steel never contacts the corrosive atmosphere.
UV-stable ASA layer — blocks sun and holds color, protects the steel from the top surface.ASA cap layer
The load-bearing heart — galvanized steel sheet gives span, rigidity and Class-A fire performance.galvanized steel core
Engineering-PVC underside seals the steel from below — acid, alkali and salt resistant.PVC base
Verified material and performance data is shown below. PSP tile is made to order, so dimensional rows are confirmed against the factory spec sheet per project — we mark those TBD rather than publish a guessed number.
| Structure | 3-layer composite — ASA cap + galvanized steel core + PVC base |
|---|---|
| Core material | Galvanized steel sheet (load-bearing) |
| Surface / base | ASA weather cap (color + UV) / engineering-PVC base (corrosion seal) |
| Width / effective width | TBD — per factory spec sheet (made to order) |
| Thickness | TBD — per factory spec sheet |
| Wave height / pitch | TBD — by profile, per factory spec sheet |
| Length | Cut to order |
| Weight | TBD — per thickness / profile |
| Service life | ≈ 25–35 yr in corrosive environments |
| Fire | Class A (national fixed-fire-fighting & fire-resistant components quality inspection centre) |
| Chemical resistance | Resistant to acids, alkalis, salts and common chemical atmospheres |
| Other | Impact resistant · load-bearing (steel core) · sound- and heat-insulating · low thermal expansion · color-stable |
| Operating temperature / wind | TBD — request test report per destination market |
PSP tile is engineered to project requirements; exact dimensions, weight and climate ratings are confirmed on the factory spec sheet and backed by test reports issued per order and destination market.
The industrial anti-corrosion choice — where ordinary steel roofing rusts out fast.
Resin skins resist fumes and acid rain that corrode metal.
Steel strength without the salt-air rusting of a bare sheet.
Long-span, load-bearing roofing for sheds and wet processing.
Three roofing lines, three jobs. PSP is the industrial anti-corrosion specialist — steel strength with a resin skin.
| Property | PSP / Plastic-Steel | Synthetic Resin | Stone-Coated Metal |
|---|---|---|---|
| Core material | Galvanized steel + resin skins | Polymer (ASA+PVC), no metal | Aluminum-zinc steel |
| Load-bearing | High (steel core) | Medium | High |
| Corrosion | Excellent (chemical-grade) | Excellent (no metal) | Good (coating-dependent) |
| Fire | Class A | B1 flame-retardant | Up to Class A |
| Best for | Industrial / chemical / coastal | Hot-climate housing, volume | Premium homes & public builds |
Not sure which line suits your project? See synthetic resin tile → · See stone-coated metal →
Made to order for the environment — we match the build to your corrosive load, span and codes.
Factory spec sheet, sample section and color chips — plus test-report pack. 24-hour quote on request.
